Comparison of AC and DC charging methods
The main types of charging for electric vehicles (EVs) are alternating current (AC) and direct current (DC), which differ in terms of efficiency, speed, and impact on the grid. The following is a deta
• 1-Phase 7KW | 3-Phase 11KW/22KW
• Type A+6mA DC(Equivalent to Type B)
• Plug-in and Charge RFID card / WIFI & Bluetooth (APP) / Ethernet
• DLB
• OCPP1.6(support upgrade to 0CPP2.0 } Optional
• CE and UKCA certified
• OCPP1.6J Series EV chargers have an lP65 patented designcase for outdoor and indoor use.
• The Type 2(IEC 62196-2) and GB/T charging connector makes highly flexible and compatible with all electric vehicles.
• Plug and start to charge automatically. (RFID card for option)
• The EV charger output power can be adjusted from 6A all the way up to 32A.
• DLB and homeuse
| TECHNICAL DATA | ||||
| DATASHEET | MODEL | SWJ3E-7/32 | SWJ3E-11/16 | SWJ3E-22/32 |
| Input | Power Supply | Single Phase | Three Phase | Three Phase |
| Rated Voltage | 220V~240V AC | 380V~400V AC | 380V~400V AC | |
| Rated Current | Max 32A (6-32A adjustable) | Max 16A (6-16A adjustable) | Max 32A (6-32A adjustable） | |
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz | |
| Output | Output Voltage | 220V~240V AC | 380V~400V AC | 380V~400V AC |
| Maximum Current | 32A | 16A | 32A | |
| Maximum Power | 7KW | 11KW | 22KW | |
| User Interface | Charge Connector | GB/T / Type 2 Cable | ||
| Cable Length | 5/7/10M Optional | |||
| Appearance Material | ABS+PC | |||
| LED Light | Green/Yellow/ Red | |||
| RFID Reader | Mifare ISO/EC 14443A (Max 5) | |||
| Startup Mode | Swipe card to use / APP / Plug in and charger | |||
| Communication | External Communication | Bluetooth / Ethernet | ||
| Other Parameters | Leakage protection | 6mA DC | ||
| other production | Over/Under Current Protection, Short Circuit Protection, Ground Protection, Surge Protection. Overload Voltage Protection, Over/Under Temperature Protection | |||
| IP level | IP65 | |||
| Environment | Temperature | -30℃-+50℃ | ||
| Humidity | 5%~95% | |||
| Altitude | <2000m | |||
| Package | Dimension | 330*163*87mm(H"W"D) | ||
| Package Dimension | 434*324*210mm (L*W*H) | |||
| Weight | 4.5kg | 5kg | 6kg | |
