DC Isolator DC300V-1000V

DC Isolator DC300V-1000V

• UV resistance and VO flame retardant material

• Contact Silver Plating, silver layer thickness up to the industry's highest standards

• Arcing Time in 3 ms

• No Polarity

• Lockable at OFF position

• IEC/EN60947.3 standard and AS 60947.3

• Provide 5-year warranty product guarantee









ELECTRICAL TECHNICAL REFERENCE

MAINCONTACTS VOLTAGE SISO-40
Rated thermal current lthe   32A
Rated insulation voltage Ui   1500V
Distance of contacts(per pole)   8mm
Rated operational current le(DC-PV2)
MAXIMUM CABLE CROSS SECTIONS (INCL. JUMPER)

4 layers, only 2layers in series, with two load

300V 32A
600V 32A
800V 16A
1000V 9A
1200V 9A

4 layers, 4 layers in series, with one load

300V 32A
600V 32A
800V 32A
1000V 32A
1200V 32A
TYPE
Number of poles   4-pole
Terminal designation, main circuit   1; 3; 5:7; 2; 4; 6; 8
Type of Conductor 4-16mnm (Rigid: solid or Stranded)
4-10mnm (Flexible)
Number of conductors per terminal   1
Required preparation of the conductor   Yes
Stipping length (mm), main circuit   8mm
Tightening torque (M4), main circuit Cable section   1.2~1.8 N.m
